To understand what is written in the section dedicated to the S700-GL, first of all, must be clear all the funtional groups thet arerepeatedly referred within the manual. For this purpose are shown in the following figure.

1. Pile
2. Sheet Feeder
3. Spring Sheet Stopper
4. Traction Group

5. Gluing Roller
6. Glue Pool with Viscosimeter
7. Sheet Feeder Plate
8. Detaching Blade
9. Belt Conveyor Traction Groupu
10.Operator Pannel
